2017 Harley-Davidson CVO Limited Photo Gallery and Specs

By - August 23, 2016

MY17 FLHTKSE CVO Ultra Limited. CVO.

The 2017 Harley-Davidson CVO Limited sports new colors, graphics, suspension and did we mention a Twin-Cooled Milwaukee-Eight 114 cu. in (1868 cc) engine? Hell yeah, it has one of those too.

MY17 Web Detail Imagery

The official word from H-D: The CVO Limited model is for road enthusiasts who want it all. All the quality. All the legacy. All the love. This premium motorcycle is the pinnacle of ultimate custom comfort, luxury, and style, and features the entire range of Project RUSHMORE enhancements. It truly raises the bar on comfort, convenience, power, style, infotainment, and confidence.

NEW IN 2017

  • Twin-Cooled Milwaukee-Eight 114 engine
  • Front and rear suspension:
  • Front suspension uses Showa Dual Bending Valve (SDBV) technology and gives you 117 mm of travel; bigger pistons improve dampening performance over the range of suspension travel
  • Hand-adjustable emulsion rear shocks provide 15-30% more preload adjustment and adjust with the turn of a single knob, no tools required; new bigger pistons improve damping performance over the range of suspension travel
  • Contrast Chrome Slicer Wheels (select color options)
  • Black Granite powder-coated engine finish with new Screamin’ Eagle inserts and badging
  • Stylized inner fairing, tank console insert, air cleaner inserts
  • Ventilator air intake design
  • Reconfigured rider seat contour, with new seat cover and stitching
  • LED tail light

MY17 Web PhotographyDIMENSIONS

Length: 102.4 in. (2600 mm)
Seat Height: 29.9 in. (760 mm)
Fuel Capacity: 6 gal. (22.7 L)
Dry weight: 906 lb. (411 kg)

POWERTRAIN

Engine: Twin-Cooled Milwaukee-Eight 114 Engine

Displacement: 114 cu. in. (1868 cc)
Engine Torque: 124 ft. lb. @ 3250 RPM (168 Nm @ 3250 RPM)
Transmission: 6-speed Cruise Drive

MY17 Lit Book ImageryWHEELS / TIRES

Wheels: Mirror Chrome Slicer Custom
Tires Front: D408F BW 130/80B17 65H
Tires Rear: D407T BW 180/65B16 81H

COLOR OPTIONS

NEW Black Garnet/Electric Red Pearl with Carbon Dust, NEW Spiked Olive/Serpentine Green with Carbon Dust, NEW Palladium Silver/Phantom Blue with Wicked Sapphire, NEW Stardust Silver/Palladium Silver with Carbon Dust
