Default HELP!!!!!!!! Clutch Cable adjustment

I am trying to adjust my clutch, the adjuster on the cable will not turn, it is siexed onto the cable, any suggestions on ho to get it to break free?

I tried to pray some lube up in it with no success.
__________________

2006 Electra Glide Classic. V&H True Duals, V&H Fishtails, SE Breather, Stage 1 ECM, Quick detach tour pak, Oil Temp Gauge, HD leather Heated Grips, 10" Wind Splitter, Freedom Wings, Kuryakyn bullet turn signal bar & Run turn brake light controller, stock road glide seat & the stock couch, Mustang Riders Backrest, Fork Deflectors and baffle, Ebay lowers, Painted Inner, 10" PYO Classic Bagger Apes, Visor trim rings,+ other odds and ends.
Reply With Quote
  #2
Old 07-20-2011, 06:51 PM
pbsdaddy's Avatar
pbsdaddy pbsdaddy is offline
Ultimate HDF Member
Join Date: Sep 2008
Location: Delaware
Posts: 6,764
Default

Hit it with some more lube. Try breakfree or PBBlaster. The issue is dissimilar metals, steel and an aluminum or aluminum compound. They oxidize which causes a bond, of sorts.
__________________
08 Ultra, 73 Sprint SX 350, 70 BSA B25
VVA life member/Chapter 850
Reply With Quote
  #3
Old 07-20-2011, 06:52 PM
10350's Avatar
10350 10350 is offline
Prospect
Join Date: Dec 2010
Location: Southeast MI
Posts: 246
Default

I would use a penetrating lube, like WD40 and then let it sit overnight. If that didn't work I would try some heat. A heat gun, not a torch. If you overheat the cable it can break inside the sheathing.
__________________


2009 FLHP 103", ABS, V&H Power duals, V&H Twin Slash Slip ons, VO2 intake, Power Commander V, SG seat, Avon grips, Streamliner boards and pegs, HD 14" tinted windshield.
Reply With Quote
  #4
Old 07-20-2011, 07:01 PM
vistavette's Avatar
vistavette vistavette is offline
Road Warrior
Join Date: Jul 2009
Location: Las Vegas, NV
Posts: 1,603
Default

A flare nut wrench will help too, better grip on the nuts
Reply With Quote
  #5
Old 07-20-2011, 07:09 PM
HDJIM1158 HDJIM1158 is offline
Road Master
Join Date: Mar 2009
Location: Daytona Beach, Florida
Posts: 1,182
Default

Hate to say it, but all that I have worked broke from rust. If you get it free up or if you buy a new one, once adjusted, make sure to put a light of grease over it under the boot. You will thank me the next time you adjust it

Be Safe JIM
__________________
2012 FLHTCU Peace Officer Special.
2009 FLHTCU Sold
2007 FLSTF, 2004 1200 Custom Sportster Sold
1998 FLHTCUI Annv. model Sold
1996 & 1999 GL 1500SE Sold
1991 FLH POLICE Sold
1984 Night Hawk 650, 1996 PC 800 Sold
Reply With Quote
  #6
Old 07-20-2011, 08:36 PM
steelerdude1's Avatar
steelerdude1 steelerdude1 is offline
Outstanding HDF Member
Join Date: Oct 2010
Location: Johnstown, PA
Posts: 2,073
Default

Quote:
Originally Posted by HDJIM1158 View Post
Hate to say it, but all that I have worked broke from rust. If you get it free up or if you buy a new one, once adjusted, make sure to put a light of grease over it under the boot. You will thank me the next time you adjust it

Be Safe JIM
Got it off, It took lubing it up and holing the cable with a rag and vice grips (lightly). Its adjusted, and greased it up for the next time.

Thanks guys.
__________________

2006 Electra Glide Classic. V&H True Duals, V&H Fishtails, SE Breather, Stage 1 ECM, Quick detach tour pak, Oil Temp Gauge, HD leather Heated Grips, 10" Wind Splitter, Freedom Wings, Kuryakyn bullet turn signal bar & Run turn brake light controller, stock road glide seat & the stock couch, Mustang Riders Backrest, Fork Deflectors and baffle, Ebay lowers, Painted Inner, 10" PYO Classic Bagger Apes, Visor trim rings,+ other odds and ends.
Reply With Quote
  #7
Old 07-20-2011, 09:40 PM
dickey's Avatar
dickey dickey is offline
Extreme HDF Member
Join Date: Mar 2010
Location: Florida
Posts: 10,356
Default

Quote:
Originally Posted by vistavette View Post
A flare nut wrench will help too, better grip on the nuts
Just like my girlfriend.
