Harley Davidson Softail: Handlebar Speaker Reviews and How-to

This article applies to the Harley Davidson Softail (2000-2014).

Unlike automobiles, stereo systems are few and far between on most motorcycles, because there really isn't a lot of room for them. Many people just use their smartphone and wireless earbuds, or even helmet speakers. However, for those of you interested in being able to fly down the highway, while blasting your favorite tunes, there are options available to you. Handlebar speakers mount directly onto your handlebars and connect to a separate head unit/amplifier, or have their own built-in amplifier and run off your MP3 player or phone. Here's the scoop.

How to Install Handlebar Speakers

Step 1 – Mount the amplifier

Amplifiers are not necessarily a separate unit, some are built into the speakers and they vary in size and weatherproof-ness. Most amplifiers in these kits are small and can mount onto the lower portion of the frame.

• First attach the amp to its bracket using the supplied bolts.
• Then locate an area to install the bracket. A common spot is located on the crash bar, on the A-frame.
• Secure the amp in place.

Step 2 – Secure the amp wire harness

Route the wire harness for the amp throughout the frame and onto the handle bars. Zip-tie the harness onto each part of the frame.

Step 3 – Mount the speakers

Each kit will come with its only special mounting bracket for the speakers. Use the bracket that fits onto your Softail and install them onto each handlebar. Use blue Loctite on the screws to ensure they do not loosen and fall off while riding.

Step 4 – Route the speaker and amp wires

Take the harness from the speakers and carefully route them along the handlebars. Locate the head unit or MP3 device and route the 3.5mm amplifier cable and speaker wires to it.

Step 5 – Wire the amp and speakers

Using the included amplifier harness connect the amp and run the power wires to the battery terminal, making sure to safely ground the negative wire. Using a multimeter, locate a 12v accessory wire on the motorcycle and splice the speaker wires to it. Connect the speakers into the amplifier. Once everything is secure, you are finished.

Featured Videos: Speaker Install

• Kuryakyn Sound of Chrome Speakers

• J&M Handlebar Mounted Speaker

Handlebar Speakers Review

Handlebar speaker systems differ in size, sound output capacity and available amplifiers. Less expensive units generally do not carry amplifiers and connect directly to the available head unit, while others use an amplifier to increase the overall sound quality and clarity of the music. Most kits also include MP3 capabilities, which allows you to connect a phone or music playing device directly to the system. Instead of picking a kit off on a whim, why don't you check out some of the best handlebar speaker sets available for your Softail.

Hogtunes Handlebar Speakers

Price – $300

Speaker Size – 2"

Internal/External Amplifier – External

Plug n' Play – No

USB/MP3/Radio – 3.5mm jack/USB

The Hogtunes handlebar speaker kit is the least expensive of all the models here. This kit is not Softail specific, and instead made to fit universally on bikes that use 7/8 in, 1 in, or 1 1/4 in diameter handlebars. One of the unique features found on this kit is its USB charging port. This port allows you to charge your audio device while riding. Although the sound is an improvement from the bike's stock form, it isn't anything to ride home about. Recommended for those budget conscious riders looking to a basic speaker kit.

Harley Davidson Boom! Handlebar Speaker Kit

Price – $429.95

Speaker Size – 3.5" with tweeters

Internal/External Amplifier – External

Plug n' Play – Yes

USB/MP3/Radio – 3.5mm jack

Are you a die-hard Harley-Davidson fan? Well, speaker seekers look no further, as the Boom! handlebar speaker kit is the aftermarket set available directly from Harley. The set features 3.5" speakers, of which are paired with an externally mounted 40 watt amplifier. All of the speaker components are sealed in a water resistant housing and come in a chrome finish. Another neat feature is the integrated control module that mounts onto your handlebar and allows you to easily control the volume output. Recommended for those that would like to keep their Harley close to its roots.

Kurykayn Handlebar Speakers

Price – $399.99

Speaker Size – 3"

Internal/External Amplifier – External

Plug n' Play – Yes

USB/MP3/Radio – 3.5mm jack

I personally believe these speakers are the best bang for your buck! Housed in chrome waterproof housings, these speakers are not only 3" in diameter, but also have built-in tweeters to help balance out the overall sound. The 50 watt external amplifier can be mounted anywhere on the bike, and the cables are direct plug and play. The ease of installation shortens the time you need to put this kit on, and also makes it fairly easy to troubleshoot if necessary. The speakers also have a nice swivel adjustment feature that allows you to easily manipulate the angle you want them mounted in. Just like the other listed kits, the 3.5mm audio jack allows you to easily plug you MP3 device to play all your favorite songs. Recommended for anyone looking for a reasonably price and nice performing American made audio system for their Softail.

J&M Deluxe Speaker Kit

Price – $559.99

Speaker Size – 4"

Internal/External Amplifier – Internal

Plug n' Play – Yes

USB/MP3/Radio – 3.5 jack

Do you consider yourself to be a fancy rider? The J&M handlebar speaker set is arguably the best on the market. At 4", the set offers the largest available speakers on this list, which use an internal amplifier. The internal amplifier allows you to remove the worry of shortening out an external amp, while allowing the speakers to blast any type of music. The speakers play crisp and clear sound and plug directly into your factory harness. Just as all of the other kits listed here, the kit requires a 12v lead in order to properly work. Recommended for those of you who don't mind spending a few extra dollars for quality.
