Arc audio, yay or nay

Thread Tools

Search this Thread

Old Mar 24, 2021 | 07:46 PM
Share
  #21
SBates08's Avatar
SBates08
Seasoned HDF Member
Joined: Jan 2013
Posts: 10,637
Likes: 1,246
From: Lake, Ms
Default
Originally Posted by Quik
thanks for tip, I will look into it. Speaker wise seems like I’ve got a good plan just need to figure out the amp. Would a single sd 2400.4 be too much?
Actually that amp would work fine. Parallel the fairing speakers on Ch1, parallel lowers on Ch2, and run the lids on their own channels for 3&4. That's based on using the 4ohm version.

Reply
0
Old Mar 24, 2021 | 07:51 PM
Share
  #22
Quik's Avatar
Quik
Thread Starter
|
Ultimate HDF Member
Joined: Oct 2016
Posts: 5,063
Likes: 2,582
From: On my bike!
Default
Originally Posted by SBates08
Actually that amp would work fine. Parallel the fairing speakers on Ch1, parallel lowers on Ch2, and run the lids on their own channels for 3&4. That's based on using the 4ohm version.
Ok thanks! So whatever amp I choose I need to get 4ohm? Sorry for all the questions, I’m just new to the audio stuff

Reply
0
Old Mar 24, 2021 | 08:03 PM
Share
  #23
SBates08's Avatar
SBates08
Seasoned HDF Member
Joined: Jan 2013
Posts: 10,637
Likes: 1,246
From: Lake, Ms
Default
Originally Posted by Quik
Ok thanks! So whatever amp I choose I need to get 4ohm? Sorry for all the questions, I’m just new to the audio stuff
No sir!!! If you chose the 2 amp route, you'd need a 1200.4 (2ohm) to run the fairing and lowers. Parallel bridged gets you up to 600 watts on that amp. The amp for lids would need to be 4ohm. On the 2400.4 (4ohm) when you parallel 2 4ohm speakers you get a 2ohm load. That amp puts out 600 watts at 2ohms. Same outcome just different amp strategies. I'd go the 2400.4 route.

Reply
0
Old Mar 24, 2021 | 08:09 PM
Share
  #24
Quik's Avatar
Quik
Thread Starter
|
Ultimate HDF Member
Joined: Oct 2016
Posts: 5,063
Likes: 2,582
From: On my bike!
Default
Originally Posted by SBates08
No sir!!! If you chose the 2 amp route, you'd need a 1200.4 (2ohm) to run the fairing and lowers. Parallel bridged gets you up to 600 watts on that amp. The amp for lids would need to be 4ohm. On the 2400.4 (4ohm) when you parallel 2 4ohm speakers you get a 2ohm load. That amp puts out 600 watts at 2ohms. Same outcome just different amp strategies. I'd go the 2400.4 route.
Wow! All of that sounds like farmer fran’s voice to me, lol The deeper I get into this the more I’m thinking I just need to bite the bullet and let a pro shop handle it and call me when they’re done!




Reply
0
Old Mar 24, 2021 | 08:18 PM
Share
  #25
teedoff65's Avatar
teedoff65
Seasoned HDF Member
5 Year Member
Liked
Loved
Community Favorite
Joined: Jul 2017
Posts: 5,749
Likes: 1,603
From: High Point, NC.
Default
Shannon, dont forget his bike is a CVO. There's more mods needed for those GZs to fit in CVO lids because of the locks, if Im not mistaken?

Reply
0
Old Mar 24, 2021 | 08:22 PM
Share
  #26
teedoff65's Avatar
teedoff65
Seasoned HDF Member
5 Year Member
Liked
Loved
Community Favorite
Joined: Jul 2017
Posts: 5,749
Likes: 1,603
From: High Point, NC.
Default
Also, since you have a CVO, don't you already have an amp in the bags for the rear speakers? Why cant you stick a small amp like the SD400 in place of those and run the new rear speakers off that, then the 1200 for the front 2 GZ pairs.

Reply
0
Old Mar 24, 2021 | 08:26 PM
Share
  #27
Quik's Avatar
Quik
Thread Starter
|
Ultimate HDF Member
Joined: Oct 2016
Posts: 5,063
Likes: 2,582
From: On my bike!
Default
Originally Posted by teedoff65
Also, since you have a CVO, don't you already have an amp in the bags for the rear speakers? Why cant you stick a small amp like the SD400 in place of those and run the new rear speakers off that, then the 1200 for the front 2 GZ pairs.
There is an amp in each bag and one in the fairing, is it possible to use the ones in the bags?

Reply
0
Old Mar 24, 2021 | 08:32 PM
Share
  #28
teedoff65's Avatar
teedoff65
Seasoned HDF Member
5 Year Member
Liked
Loved
Community Favorite
Joined: Jul 2017
Posts: 5,749
Likes: 1,603
From: High Point, NC.
Default
Originally Posted by Quik
There is an amp in each bag and one in the fairing, is it possible to use the ones in the bags?
No I meant replace the ones in the bag with a new amp back there to power the lids, since that is already a space for an amp. Then you dont have to work out how to put two amps in the fairing.

Reply
0
HD Forum Stories

The Best of Harley-Davidson for Lifelong Riders

story-0

7 Times Harley-Davidson Chucked Tradition Out the Window

 Verdad Gallardo
story-1

7 Surprising Harley-Davidson Products that Are Not Motorcycles

 Verdad Gallardo
story-2

8 Best Harley-Davidson Motorcycles Ever

 Pouria Savadkouei
story-3

10 Worst Harley-Davidson Motorcycles Ever

 Pouria Savadkouei
story-4

Killer Custom's Jail Break Is The Breakout That Refused to Blend In

 Verdad Gallardo
story-5

Crazy Bunderbike Build Looks Amazing, But Is It Impossible to Ride?

 Verdad Gallardo
story-6

Harley-Davidson Reveals Super Cool Cafe Racer Concept

 Verdad Gallardo
story-7

Engraved Rebellion: Inside Bundnerbike's Glam Rock II

 Verdad Gallardo
story-8

10 Motorcycles You Should Never Buy

 Joe Kucinski
story-9

10 Things Harley-Davidson Needs to Fix in 2026

 Verdad Gallardo
Old Mar 24, 2021 | 08:38 PM
Share
  #29
SBates08's Avatar
SBates08
Seasoned HDF Member
Joined: Jan 2013
Posts: 10,637
Likes: 1,246
From: Lake, Ms
Default
Originally Posted by teedoff65
Shannon, dont forget his bike is a CVO. There's more mods needed for those GZs to fit in CVO lids because of the locks, if Im not mistaken?
They'll still fit. I've gotta buddy running them in the CVO lids. I can get pics this wknd.

Reply
0
Old Mar 24, 2021 | 08:40 PM
Share
  #30
teedoff65's Avatar
teedoff65
Seasoned HDF Member
5 Year Member
Liked
Loved
Community Favorite
Joined: Jul 2017
Posts: 5,749
Likes: 1,603
From: High Point, NC.
Default
Originally Posted by SBates08
They'll still fit. I've gotta buddy running them in the CVO lids. I can get pics this wknd.
Will an SD400 power those?
