Need some electrical advice
Elite HDF Member
Joined: Oct 2005
Posts: 3,872
Likes: 83
From: Canton, Michigan
After consulting one of my grandsons, that's what we think they are saying too....
In any case, I'm certain it's dead, so needs replaced anyway. I figure adding the capacitor can't hurt anything, so I may add well give it a try.
Seasoned HDF Member
Joined: Aug 2007
Posts: 8,197
Likes: 3,087
From: NW AR
You kinda need a capacitor to smooth out that ripple. And I'm fairly certain that the regulator died because it wasn't designed to run with no battery. I think that after your discussion with CE, I would be confident in running what they make for you.
Elite HDF Member
Joined: Oct 2005
Posts: 3,872
Likes: 83
From: Canton, Michigan
I would ask CE if the CE-208NB has internal capacitor, thus eliminating the need for one in your last drawing.
Last edited by Hackd; Oct 6, 2018 at 03:39 PM.
Seasoned HDF Member
Joined: Mar 2010
Posts: 21,076
Likes: 7,601
From: Poolville
Hey man, How you making out?
Quick question, from the get go..... Was this an issue? Or did it work for a while then go south at higher RPM's. Have you tried a battery just to see what happens...?
Quick question, from the get go..... Was this an issue? Or did it work for a while then go south at higher RPM's. Have you tried a battery just to see what happens...?
Why are you guys so bound and determined to talk me into mounting a battery? I can see a clear disadvantage (having to have some sort of on-off switch), but what's the advantage? I feel like I'm missing something.
Edit: To answer your question, I can't really say if it was working 100% initially, but I think it was. I do know that after a period of time the dimming at speed problem got progressively worse, until it finally more or less died.
Last edited by 0maha; Oct 8, 2018 at 04:07 PM.
Seasoned HDF Member
Joined: Aug 2007
Posts: 8,197
Likes: 3,087
From: NW AR
I think it's cool without the battery. You just need the right regulator. Maybe a capacitor, but definitely the right regulator.
HD Forum Stories
The Best of Harley-Davidson for Lifelong Riders
8 Best Harley-Davidson Motorcycles Ever
Pouria Savadkouei
10 Worst Harley-Davidson Motorcycles Ever
Pouria Savadkouei
Killer Custom's Jail Break Is The Breakout That Refused to Blend In
Verdad Gallardo
Crazy Bunderbike Build Looks Amazing, But Is It Impossible to Ride?
Verdad Gallardo
Harley-Davidson Reveals Super Cool Cafe Racer Concept
Verdad Gallardo
Engraved Rebellion: Inside Bundnerbike's Glam Rock II
Verdad Gallardo
10 Motorcycles You Should Never Buy
Joe Kucinski
10 Things Harley-Davidson Needs to Fix in 2026
Verdad Gallardo
Southpaw Super Glide: A Left-Hand-Drive 1979 Harley FXE Built to Fit the Rider
Verdad Gallardo
Seasoned HDF Member
Joined: Mar 2010
Posts: 21,076
Likes: 7,601
From: Poolville
Not trying to push you into anything. Just a process of elimination is all... Have you done an AC rest on the alternator. 1000 RPM = 16-20 vac and 2000 RPM= 32-40vac.. just to confirm proper operation....
Last edited by 98hotrodfatboy; Oct 9, 2018 at 11:07 AM.
Elite HDF Member
Joined: Oct 2005
Posts: 3,872
Likes: 83
From: Canton, Michigan
The capacitor in your last drawing acts like a battery in the circuit. It also smooths out the voltage/power requirements from your lighting.
I'm with Dr. Hess: You don't need a battery, just the correct VR.
I'm with Dr. Hess: You don't need a battery, just the correct VR.
