Greetings to all of you!
As a member of this forum I would like to share some information on H-D instruction sheets with you.
Below you will find a database I was able to set up with the help of mud
** posting #1 shows the parts in numerical order < 58000-XX**
** posting #4 shows the parts in numerical order > 58000-XX**
** posting #2 shows the p/n's in alphabetical order A - H**
** posting #2 shows the p/n's in alphabetical order F - Z**
When you click the bold link (p/n) you will get access to the pdf file.
The database is far from being complete; just give me some time to do more research and add the info to the database.
Any addition from your side is more than welcome, just let me know in this thread.
Kind regards,
FXD2003Rider
numerical.....
.
.
16550-04 ...cylinder kit big bore SE mud 9-17-09
revision 2007-09-12
.
17378-98 ...Screamin' Eagle® Roller Rocker Arms (fits '84-'99 Evolution® 1340-equipped models, '86-later XL and XR models and '99-later Twin Cam-equipped models. Modification is required on Twin Cam rocker™ covers.) (added 10-31-2009) contribution of: wireguided
.
17675-01B ...Screamin' Eagle® Forged Rocker Supports for Twin Cam Models (fits '99-later Twin Cam equipped models) (added 10-31-2009) contribution of: wireguided
.
17997-99A ...pushrods adjustable mud 9-14-09
.
18096-00A ...pushrod covers mud 9-14-09
.
18404-08 ...high performance quick-install adjustable pushrods (added 10-30-2009) contribution of: wireguided
.
25282-07...cam support plate mud 9-13-09
.
25284-08 ...hybrid cam plate and high flow oil pump kit (added 10-30-2009)
.
26081-05 ...Dyna Oil Cooler Kit (added 04-22-2011)
.
26151-07 ...Premium Oil Cooler Kit for Dyna® Models (Fits '06-later Dyna® models (except FXDSE/2, FXDFSE and California models). Does not fit with Front Spoiler Kits or Definitive5™ Filtration System Kits. Fits with all H-D® Engine Guards.) (added 11-08-2009)
.
27505-09 ...Screamin' Eagle 110 cubic inch stage I kit (fits '09 FXDF models) (added 10-30-2009)
.
29098-09 ...SE heavy breather performance air cleaner kit (added 09-19-2009)
.
29243-97 and 29244-97 Chrome air cleaner trim insert (used on Evo engine 8 inch A/C cover)
.
29299-08 ...SE heavy breather performance air cleaner kit (added 09-19-2009)
.
31705-04 ...dyna chrome coil cover kit (fits carburated versions) (added 10-26-2009) contribution of: 2007fxdc
.
31709-04 ...dyna chrome coil cover kit (fits EFI versions) (added 10-26-2009) contribution of: 2007fxdc
.
37970-03A ...clutch SE race mud 9-14-09
.
40063-05A ...automatic primary chain tensioner (added 09-15-2009)
.
40274-08 ...big twin compensator mud 9-13-09
.
43768-06 ...wide tire kit mud 9-17-09
.
43911-95 ...head bolt covers
.
44090-00 ...dual disc brake kit (will fit on '88-later XL, FXR and FXD models) (added Jan. 27-2010)
.
45023-02 ...triple tree
.
45030-03C ...black front master cylinder cover (Fits '96-'05 Dyna models) (added 01-13-2011)
.
45075-08 ...chrome hand control lever kit Fits '08-later Dyna® and Softail® models (added Jan. 01-2010)
.
45075-07 ...chrome hand control lever kit Fits '96-'03 XL models and '96-'07 Dyna®, Softail® and Touring models. (Does not fit Police models, VRSC™ models, or models equipped with hydraulic clutch.)(added Jan. 01-2010)
.
45078-96D ...chrome front master cylinder cover (Fits '96-'05 Dyna models) (added 01-13-2011)
.
45740-07 ...steering head washer kit (all 2006-2007 Dyna and 2008 and earleir FXDWG models) (added 11-06-2009)
.
46193-99 ...fork brace 39-41mm mud 9-14-09
.
46423-05A ...black front master cylinder cover kit (2006 - up Dyna models) (added 01-13-2011)
.
46424-05A ...chrome front master cylinder cover kit (2006 - up Dyna models) (added 01-13-2011)
.
46586-06 ...dyna chrome fork slider kit '06 and later (not for FXDWG, FXDF, FXDFSE & FXDSE/2) (added 10-17-2009)
.
46589-06 ...dyna fxdwg chrome fork slider kit (added 10-17-2009)
.
46595-06 ...fork brace 49mm mud 9-14-09
.
46646-05 ...brake rotor hardware kit (front) mud 9-18-09
.
48439-00B ...dyna chrome swingarm ('00 - '05 models) added 10-30-2009
.
48458-06 ...dyna chrome swingarm ('06 - '09 models) (added 10-30-2009) contribution of: wireguided
.
49021-09 ...dyna fwd control kit gloss black '06-later models (added 09-20-2009)
.
49080-03A ...dyna fwd control kit chrome '03-'05 models (added 09-20-2009)
.
49080-06A ...dyna fwd control kit chrome '06-later models (added 09-20-2009)
.
49279-06...dyna passenger footboard support kit (added 09-16-2009)
.
50210-06 ...passenger footpeg mounting kit (added 06-04-2010)
.
50357-04 ...swept-wing grooved passenger footboard kit (added 09-16-2009)
.
50451-09 ...mini footboard kit (added 10-21-2009)
.
50500247 Dyna Rider Foorboard Kit (for ’06-later FXD, FXDB, FXDC and FXDL models) (added 08/29/20125)
.
50601-01 ...Dyna Floorboard kit (added 09-14-2009) kit is obsolete; individual p/n's still available!
27-0920 ... Substitute by V-Twin Mfg(added 02-12-2010)
.
50886-02 ...Dyna Passenger Footboard Kit (fits 2002-2005 Dyna Models)
(added 12-31-2011)
.
53527-95A ...dyna docking hardware (added 09-25-2009)
.
53961-06...dyna docking hardware kit (added 09-19-2009) contribution of ackman1968
.
53964-06A...FXWG docking hardware kit (added 09-19-2009) contribution of sanlyn
.
53968-06 ...directional relocation kit (added 09-19-2009) contribution of ackman1968
.
55975-08A...street slammer handlebar kit (added 17-09-2009)
.
55977-09 ...fatbob handlebar kit mud 9-13-09
.
56165-03 ...handlebar polyurethane riser bushing kit (added 09-27-2009)
.
56290-05 ...deluxe pullback riser and clamp kit (added 10-11-2009)
.
56679-02 ...100th Anniversary handlebar grips (added 11-19-2009)
.
56916-07 ...handlebar riser kit fatbob mud 9-17-09
.
57340-08 ...detachable windshield and quick-clamp docking kit 49mm forks (added 10-03-2009)
.
57716-01 ...compact replacement windshield kit
.
For p/n's > 58000-XX go here
