Took my handlebars off

Reply Subscribe

Thread Tools

Search this Thread

Jun 1, 2016 | 03:07 PM

#81

DeputyLoud

Road Captain

Joined: Jul 2014

Posts: 721

Likes: 18

From: Galesville, WI

Quote:

Originally Posted by 0maha

OTOH, I just remeasured the stockers I took off, and they are almost exactly equal to the 12"s. Maybe a half inch longer is all.

Think I'll run this past the indy next door and see what he thinks.

Good bit of info right there! Safe ride brother, Enjoy the new setup!

Jun 1, 2016 | 03:34 PM

#82

89FLHTC

Supporter

Joined: Oct 2015

Posts: 1,170

Likes: 32

From: Ft.Worth, Texas

Damn..that turned out bitchin' ! I told you the bike would feel more nimble. Tight turns are a breeze. They will pay for themselves on your next long trip. If you jack the bike up with your jack and there is still some slack in the front brake lines, they should be fine. Did you end up running an air line to the back of the bike for your front forks?

Jun 1, 2016 | 03:40 PM

#83

0maha

Thread Starter

Seasoned HDF Member

Joined: Nov 2012

Posts: 6,555

Likes: 4,805

From: Omaha

Quote:

Originally Posted by 89FLHTC

Did you end up running an air line to the back of the bike for your front forks?

No, I just got some fuel line from Ace Hardware, a barbed fitting, a hose clamp and a cap for the fitting. It's all stuffed up under the batwing. No way to pressurize the system, but it is sealed and I can still do the vacuum fork oil change.

Jun 1, 2016 | 05:11 PM

#84

Beemervet

Ultimate HDF Member

Joined: May 2006

Posts: 6,590

Likes: 444

From: Ohio

Looks good, nice choice of bars, you will really like them on the road.

Jun 2, 2016 | 06:43 AM

#85

traildog

Seasoned HDF Member

Joined: Sep 2010

Posts: 10,238

Likes: 799

From: Indiana

Lookin good Omaha.....pretty sure I snapped a pic of ya last night.....

Jun 2, 2016 | 09:16 AM

#86

DeputyLoud

Road Captain

Joined: Jul 2014

Posts: 721

Likes: 18

From: Galesville, WI

Quote:

Originally Posted by 0maha

Murphy has been doing his best to beat the crap out of me on this project as it is. He deserves some abuse!!!!

Loving life right now. This thing arrived this morning, and it looks like it should line up perfectly:

Looking closer at this manifold setup it is different than the Russell one I got. On mine all 3 lines are threaded into the manifold. Yours are pressed in by the looks of it. Just for giggles when I get back into my garage I'll snap a pic of what I got since I have the fairing off at the moment. I imagine maybe it's just the difference in the model years? Simply an observation.

Edit: Pic as promised.

Attached Thumbnails

Took my handlebars off-wp_20160602_21_16_23_pro.jpg

Last edited by DeputyLoud; Jun 3, 2016 at 01:22 PM.

Jun 2, 2016 | 10:37 AM

#87

0maha

Thread Starter

Seasoned HDF Member

Joined: Nov 2012

Posts: 6,555

Likes: 4,805

From: Omaha

Finalizing some stuff here. My final parts list:

- WildOne WO577 12.5" bars
- WildOne WO538 single piece top clamp
- Barnett +6 clutch, throttle and idle cables

For the brake lines, everything is Russell (Drag Specialties part numbers):

- Tee/Splitter thing that goes under the triple clamp: 1742-0016
- Top hose: 26". Could have gone a bit shorter, but the excess is hidden in the batwing: 1741-0074
- Bottom hoses: 12". Double checked, and these are plenty long: 1741-0066
- Went with 35 degree banjos at the MC and the calipers: 1742-0019

Jun 2, 2016 | 05:25 PM

#88

14GuineaPig

Stellar HDF Member

Joined: Sep 2013

Posts: 3,492

Likes: 610

From: USA

It looks great and you came in on time. Enjoy your ride.

HD Forum Stories

The Best of Harley-Davidson for Lifelong Riders

7 Times Harley-Davidson Chucked Tradition Out the Window

Verdad Gallardo

7 Surprising Harley-Davidson Products that Are Not Motorcycles

Verdad Gallardo

8 Best Harley-Davidson Motorcycles Ever

Pouria Savadkouei

10 Worst Harley-Davidson Motorcycles Ever

Pouria Savadkouei

Killer Custom's Jail Break Is The Breakout That Refused to Blend In

Verdad Gallardo

Crazy Bunderbike Build Looks Amazing, But Is It Impossible to Ride?

Verdad Gallardo

Harley-Davidson Reveals Super Cool Cafe Racer Concept

Verdad Gallardo

Engraved Rebellion: Inside Bundnerbike's Glam Rock II

Verdad Gallardo

10 Motorcycles You Should Never Buy

Joe Kucinski

10 Things Harley-Davidson Needs to Fix in 2026

Verdad Gallardo

Jun 2, 2016 | 06:48 PM

#89

0maha

Thread Starter

Seasoned HDF Member

Joined: Nov 2012

Posts: 6,555

Likes: 4,805

From: Omaha

First leg of the trip is behind us. We are settled in in glorious Broken Bow, Nebraska. Bike ran great. New bars are wonderful. Totally worth the swap.
