Compensator nut torque value
Guys, I am looking for the torque value for the compensator nut for a 1988 FLHTC (Electra Glide), I do NOT have a HD manual, but I do have the Clymer manual and it spans for several years, and they state 90ft pounds (with red lock tight), just wondering if anyone from the Evo family has a HD manual for that specific year, so that I can have the "official" spec, thanks.
Seasoned HDF Member
Joined: Jul 2014
Posts: 8,632
Likes: 3,393
From: Cental, MI
I thought 90lbs with loctite, was for the Clutch nut??? But.. I would need to go Look at the Service Manual..
I cannot Imagine taking my Harley that far apart, without the Genuine Service Manual.. you just showed us what "other" manuals are worth!!!
I cannot Imagine taking my Harley that far apart, without the Genuine Service Manual.. you just showed us what "other" manuals are worth!!!
Grand HDF Member
Joined: Apr 2007
Posts: 3,728
Likes: 3,073
From: Brighton, MI
Last edited by Yankee Dog; Jun 13, 2024 at 03:38 PM.
Seasoned HDF Member
Joined: Mar 2010
Posts: 21,168
Likes: 7,676
From: Poolville
HDF Community Team
Joined: Jul 2021
Posts: 175
Likes: 142
From: Wilmington, NC
Guys, I am looking for the torque value for the compensator nut for a 1988 FLHTC (Electra Glide), I do NOT have a HD manual, but I do have the Clymer manual and it spans for several years, and they state 90ft pounds (with red lock tight), just wondering if anyone from the Evo family has a HD manual for that specific year, so that I can have the "official" spec, thanks.
I highly encourage all to get a service manual (there are two for the softtail). One is 85-90, and the other is a “big twin” 87-90. BOTH are helpful. You should be able to find the latter one free somewhere. It has a yellowish cover.
Also, get yourself an MPC. You will not regret it!
