electrical problems
I had my 08 Fxdl out for a ride today and about 5 mins into the ride it shuts completley off. I pulled over and and tried to start it up, fuel pump didnt kick on nor did the engine roll over. so I took off the battery cover and everything looked fine so I looked at the fuse link. the 7.5 amp fuse was broke off at one one prong, also noticed the ingnition fuse was blown. I just had 16 inch ape hangars with 3 inch risers installed. So I threw in a 10 amp and a 20 get me homeI have a question what is the 7.5 fuse for and what could be causing that. Im guessing a short in the bars. All and any help what be appreciated. Thanks
Last edited by Kinger84; Dec 25, 2012 at 08:26 PM. Reason: forgot words
I had my 08 Fxdl out for a ride today and about 5 mins into the ride it shuts completley off. I pulled over and and tried to start it up, fuel pump didnt kick on nor did the engine roll over. so I took off the battery cover and everything looked fine so I looked at the fuse link. the 7.5 amp fuse was broke off at one one prong, also noticed the ingnition fuse was blown. I just had 16 inch ape hangars with 3 inch risers installed. So I threw in a 10 amp and a 20 get me homeI have a question what is the 7.5 fuse for and what could be causing that. Im guessing a short in the bars. All and any help what be appreciated. Thanks
Outstanding HDF Member
Joined: Oct 2012
Posts: 2,267
Likes: 1
From: Redcar Cleveland England
Hello from Redcar England.
I am not an expert with the wires side of things but it sounds like you have it covered going to the last thing that has been touched. Please give feed back when you have got it sorted because if its happened to you it could happen to others. I ride a dyna so if its a dyna fault pass it on so we no.
Good luck and all the best for the new year.
fxdxi rider
tbone.
I am not an expert with the wires side of things but it sounds like you have it covered going to the last thing that has been touched. Please give feed back when you have got it sorted because if its happened to you it could happen to others. I ride a dyna so if its a dyna fault pass it on so we no.
Good luck and all the best for the new year.
fxdxi rider
tbone.
If you were able to put a bigger fuse in and it held, I doubt it is a short, unless you burned off the wire that was causing the short, or it is on a switched wire that you have not switched since replacing fuse..
You said the fuse was broke off? How did that happen, that may have caused the problem..
You said the fuse was broke off? How did that happen, that may have caused the problem..
Outstanding HDF Member
Joined: Nov 2007
Posts: 2,289
Likes: 22
From: Beautiful Downtown Burbank
The blown ign fuse is the result of a problem you have. Either the wires got scarred when fishing them through the bars, or one got pinched somewhere
