Shovel trouble!
Thread Starter
|
3rd Gear
Joined: Dec 2019
Posts: 7
Likes: 3
From: Midwest
Shovel trouble!
First off, I have been riding the same shovel for sometime now and and never had much problem. I did have it bored and stroked several years ago, maybe 7,000 miles on the motor now. The problem I’m having is this summer the rear plug would “short out “ for lack of a better word, after about 100 miles. Plug looks good, identical to the front as far as color. Perhaps a little rich but looks fine. Just “shorts out” I tried every brand of plugs I could find but nothing helped. Ended up with 5R6A HD plugs when I parked it for the winter.
I cant figure it out! Normally I can run a set all year without problems. Thought I had an ignition switch problem, replaced it... tah dah same problem! Nobody locally has had an idea hopefully someone here can help save the old girl from a life of collecting dust!
It’s an 82 shovel bored 30 stroked to an 84” (I believe) S&S carb and heads Hi-4 ignition.
Thanks!
I cant figure it out! Normally I can run a set all year without problems. Thought I had an ignition switch problem, replaced it... tah dah same problem! Nobody locally has had an idea hopefully someone here can help save the old girl from a life of collecting dust!
It’s an 82 shovel bored 30 stroked to an 84” (I believe) S&S carb and heads Hi-4 ignition.
Thanks!
Banned
Joined: Jan 2017
Posts: 17,008
Likes: 14,675
From: in a cave at the foothills
If you don't get the help here try posting in the shovel section of the forum. But pics of your bike would be welcome and customary.
https://www.hdforums.com/forum/shovelhead-62/
https://www.hdforums.com/forum/shovelhead-62/
Thread Starter
|
3rd Gear
Joined: Dec 2019
Posts: 7
Likes: 3
From: Midwest
If you don't get the help here try posting in the shovel section of the forum. But pics of your bike would be welcome and customary.
https://www.hdforums.com/forum/shovelhead-62/
https://www.hdforums.com/forum/shovelhead-62/
Factory
Finished
Bringing the Stroker home! 😂
Well it’s a Harley so you guys may get a kick out of it! 1975 HD SS250cc with a 6” swing arm extension. Burned up the top end this spring at a the Logan Iowa Hillclimb. Apparently the oil injection stopped working! Hopefully up and running by March for Logan again!
Last edited by NomadShovel; Dec 14, 2019 at 11:49 AM.
Road Master
Joined: Jun 2013
Posts: 1,239
Likes: 1,171
From: St. Catharines, Ontario
please explain "shorting out"
Do you have an ohmeter available to you?
When this happens does the engine keep running on the front only?
If you replace the plug with a new one does the bike fire up?
Do you have an ohmeter available to you?
When this happens does the engine keep running on the front only?
If you replace the plug with a new one does the bike fire up?
Trending Topics
Thread Starter
|
3rd Gear
Joined: Dec 2019
Posts: 7
Likes: 3
From: Midwest
Baird
I do have an ohmmeter. Yes it keeps running on the front cylinder but the rear cuts out, it does keep running but horribly and pops frequently. Soon as I replace the plug it runs like a top again for another 100 miles. The bike is kick only and still has good compression. Haven’t checked it but my 200 lb carcass can still hardly kick it over.
HD Forum Stories
The Best of Harley-Davidson for Lifelong Riders
7 Surprising Harley-Davidson Products that Are Not Motorcycles
Verdad Gallardo
8 Best Harley-Davidson Motorcycles Ever
Pouria Savadkouei
10 Worst Harley-Davidson Motorcycles Ever
Pouria Savadkouei
Killer Custom's Jail Break Is The Breakout That Refused to Blend In
Verdad Gallardo
Crazy Bunderbike Build Looks Amazing, But Is It Impossible to Ride?
Verdad Gallardo
Harley-Davidson Reveals Super Cool Cafe Racer Concept
Verdad Gallardo
Engraved Rebellion: Inside Bundnerbike's Glam Rock II
Verdad Gallardo
10 Motorcycles You Should Never Buy
Joe Kucinski
10 Things Harley-Davidson Needs to Fix in 2026
Verdad Gallardo
Seasoned HDF Member
Joined: Oct 2012
Posts: 11,224
Likes: 3,049
From: St.Louis Mo.
Is it oil fouled or gas fouled ? Can you run it in duel fire mode and switch the plug wires around and see if it runs better. I'm betting something wrong with the HI 4 system you have in there. When it stops running will it restart after it cools down ?
Road Master
Joined: Oct 2019
Posts: 932
Likes: 593
From: Connecticut
You didn't mention what ignition you're running, and single or dual fire.
My take, if it ain't the plugs its a sparkplug cable, or coil. Everything else depend on what system you're running.
Nice bike!
My take, if it ain't the plugs its a sparkplug cable, or coil. Everything else depend on what system you're running.
Nice bike!
