Shovelhead inner primary cover
I recently purchased 1982 FLH.Bike had bad oil leak transmision shaft seal appears to be culprit.I was putting on inner primary case when I tighten down unable to spin wheel,wheel spins free until tighten down ? Any ideas? Thnx
Road Master
Joined: Jun 2019
Posts: 952
Likes: 528
From: Richmond TX
Your transmission and engine may not be aligned in the frame. I would see if you can find a procedure to handle the alignment. I'm guessing, but either the engine or the transmission is likely tightened in first while the other one is loose bolted such that it can float a bit. Snug up the chaincase, then torque the motor or transmission and then torque the chaincase.... something like that. Get the right info before proceeding if you can. The complication is rear wheel drive alignment, got to end up close enough to handle that. Hoping this helps.
Seasoned HDF Member
Joined: May 2008
Posts: 21,093
Likes: 12,638
From: South Carolina
Don`t tighten primary cover bolts while transmission is bolted tight, loosen the transmission bolts, it needs to be loose so that it will pull up to the inner primary cover.
You need to be working with a factory service manual to do this work, unless you really like buying inner primary covers.
You need to be working with a factory service manual to do this work, unless you really like buying inner primary covers.
Intermediate
Joined: Jun 2020
Posts: 29
Likes: 8
From: AR
Last edited by Rchilton; Jun 7, 2020 at 11:17 PM. Reason: Wrong thread.
Intermediate
Joined: Jun 2020
Posts: 29
Likes: 8
From: AR
Slow going.
