Extending wires

Reply Subscribe

Thread Tools

Search this Thread

Jan 7, 2019 | 10:32 PM

#11

Larry the Landlord

Road Captain

Joined: Jul 2009

Posts: 540

Likes: 36

From: Tulsa Ok

I’ve done apes on my 2 road kings. My 02,I soldered extensions, 30,000 miles, no problems. I just did my 2014, Namz extensions, would have been great if they sent all the wiring I needed. No extensions for tthe TBW and I had to solder extensions for the turn signals. I wasn’t impressed.

Feb 20, 2019 | 07:24 AM

#12

Sethc1020

Tourer

Joined: Jun 2018

Posts: 437

Likes: 107

From: Indiana

Quote:

Originally Posted by Studlintsean

Here is the link: https://hillcountrycustomcycles.com/...-davidson.html

On this it says CAN is for models 2012 up but I was under the impression CAN wasn't used until 2014. Is there an easy way to find out if my 2012 RG Ultra is CAN or wires?

Quote:

Originally Posted by BB59

The job could certainly be done with bulk wire if you wanted to go that route. On the pre CANBUS models there will be a lot of wires in those harnesses, maybe 10- 20 each side. If using bulk wire as opposed to a wiring kit you would want to keep the factory terminals ends on all of the wires meaning you would be making two splices in each wire as opposed to one splice with the extension kit which comes with terminal ends attached.
You didn't mention if you plan on internally wiring your new bars. If so that is a lot of splices to fit and pull through the bars. Here is a link to the Namz kit I have used on that model bike ... $56.00. The bulk wire, unless you already have it, will cost something.

https://namzcustomcycleproducts.com/...ultras-glides/

For a few bucks more I use the longer extensions allowing me to stagger the splices better inside the bars. .

What about extensions for the brake line and clutch cable? Im about to put some 14" klock Werks on my 2012 RG Ultra and want to make sure I have eveything I need before I get started.

Feb 20, 2019 | 07:53 AM

#13

SBates08

Seasoned HDF Member

Joined: Jan 2013

Posts: 10,637

Likes: 1,246

From: Lake, Ms

Quote:

Originally Posted by Sethc1020

On this it says CAN is for models 2012 up but I was under the impression CAN wasn't used until 2014. Is there an easy way to find out if my 2012 RG Ultra is CAN or wires?What about extensions for the brake line and clutch cable? Im about to put some 14" klock Werks on my 2012 RG Ultra and want to make sure I have eveything I need before I get started.

Your bike is not CANBUS and there's no such thing as extensions for the clutch cable and brake line. They have to be replaced with a longer cable and line if you're going higher than a 10" bar.

Feb 20, 2019 | 09:34 AM

#14

Sethc1020

Tourer

Joined: Jun 2018

Posts: 437

Likes: 107

From: Indiana

Quote:

Originally Posted by SBates08

Your bike is not CANBUS and there's no such thing as extensions for the clutch cable and brake line. They have to be replaced with a longer cable and line if you're going higher than a 10" bar.

Thats what I was thinking. I see kits for around $300 that come with the wires, clutch cables and brake lines. Would it be cheaper to just buy them all separate? If so where is the best place to find the clutch cable and brake lines? Going with 14" bars.

Last edited by Sethc1020; Feb 20, 2019 at 09:50 AM.

Feb 20, 2019 | 10:08 AM

#15

cprhed

Stellar HDF Member

Joined: Feb 2015

Posts: 2,957

Likes: 1,175

From: South Dakota

Quote:

Originally Posted by Sethc1020

Magnum is where you want to look. They sell clutch, brake, wire kits. the works. I see it looks like you already ordered a wire kit though. Personally for me that was a no go. I did not want a plug in type connection up inside the bar. If that works loose I have to completely disassemble.
I soldered mine. Not for everyone of course. Not everyone can. I can so I did. I can't weld so I don't. simple as that. If you look at magnum Call Them with questions. They are great about helping you measure to make sure you get what you need. My bars were 12 inch which is +4 over stock. However. For one I went +4 for the other I went +6, +4 would have been too tight. This was based on measurements the gal at Magnum gave me instructions for. Big help.
Here is my thread if you are interested. My build thread

https://www.magnumshielding.com/

Feb 20, 2019 | 12:35 PM

#16

Sethc1020

Tourer

Joined: Jun 2018

Posts: 437

Likes: 107

From: Indiana

Quote:

Originally Posted by cprhed

Thanks a lot! Very helpful and your thread was very informative. About to purchase my Magnum kit now!

Feb 20, 2019 | 10:28 PM

#17

Ragtop

Ultimate HDF Member

Joined: Sep 2006

Posts: 7,101

Likes: 1,013

I did the soldering route, pretty easy, and only used $5 worth of wire. Too me an hour or so for the wiring part.
To me, it seemed easier than pulling the pins.
These were Wild One's 10" mini apes
