Tank Lift or Not?
Stellar HDF Member
Joined: Mar 2006
Posts: 3,124
Likes: 255
From: From Long Island, now in So. Cal
Yes....
You have to open up the tank under the console and remove the sending unit.
I put a half gallon in then I bent the float rod right by the sending unit (the rod has a "V" shape angle there). I opened that angle up a little, re-installed sending unit and with the bike upright and my weight on it, I recycled the power and run switch and waited for the gauge to settle (there's a delay in the circuit). I had to do this several times to get it right where I wanted it.
Now when the low fuel light comes on I have a half gallon left. Also when my gauge is now reading a half tank and I top it off I usually pump in about 2.2 to 2.3 gallons (4.7 gallon tank)
While your in there you might as well check your internal fuel lines, info here:
https://www.hdforums.com/forum/dyna-...fuel-line.html
I put a half gallon in then I bent the float rod right by the sending unit (the rod has a "V" shape angle there). I opened that angle up a little, re-installed sending unit and with the bike upright and my weight on it, I recycled the power and run switch and waited for the gauge to settle (there's a delay in the circuit). I had to do this several times to get it right where I wanted it.
Now when the low fuel light comes on I have a half gallon left. Also when my gauge is now reading a half tank and I top it off I usually pump in about 2.2 to 2.3 gallons (4.7 gallon tank)
While your in there you might as well check your internal fuel lines, info here:
https://www.hdforums.com/forum/dyna-...fuel-line.html
Advanced
Joined: Jan 2015
Posts: 64
Likes: 0
From: Ohio
Installed my front and rear this weekend and besides the seat fitment from the rear lift it was cheap/easy and I love it. Looks alot better.
