Absolutely cannot get compensator nut off
Seasoned HDF Member
Joined: Mar 2010
Posts: 38,640
Likes: 6,445
From: Honah Lee
I use a 3/4 drive impact. I do step the compressor up 150 just like you mentioned. Do not put a 6 ft bar on it. I lock sprocket with a hard delrin step block but Harley recommends a bar wedge.
You can use a long bar but use an extension on socket drive. Carefully set a heavy jack stand up close to breaker bar. That way you are driving it around on compensator but only pushing down at jack stand.
Watch that heat. You need to take a hard look at the alternator rotor magnets when you get it apart.
PS.. I do this with bike on wood blocks under frame. If I had to resort to bar, I sure would be on blocks with someone straddling the front wheel. Not on a jack.
You can use a long bar but use an extension on socket drive. Carefully set a heavy jack stand up close to breaker bar. That way you are driving it around on compensator but only pushing down at jack stand.
Watch that heat. You need to take a hard look at the alternator rotor magnets when you get it apart.
PS.. I do this with bike on wood blocks under frame. If I had to resort to bar, I sure would be on blocks with someone straddling the front wheel. Not on a jack.
Last edited by Jackie Paper; Aug 27, 2021 at 06:11 PM.
Road Captain
Joined: Dec 2015
Posts: 650
Likes: 355
From: connecticut
I use a 3/4 drive impact. I do step the compressor up 150 just like you mentioned. Do not put a 6 ft bar on it. I lock sprocket with a hard delrin step block but Harley recommends a bar wedge.
You can use a long bar but use an extension on socket drive. Carefully set a heavy jack stand up close to breaker bar. That way you are driving it around on compensator but only pushing down at jack stand.
Watch that heat. You need to take a hard look at the alternator rotor magnets when you get it apart.
PS.. I do this with bike on wood blocks under frame. If I had to resort to bar, I sure would be on blocks with someone straddling the front wheel. Not on a jack.
You can use a long bar but use an extension on socket drive. Carefully set a heavy jack stand up close to breaker bar. That way you are driving it around on compensator but only pushing down at jack stand.
Watch that heat. You need to take a hard look at the alternator rotor magnets when you get it apart.
PS.. I do this with bike on wood blocks under frame. If I had to resort to bar, I sure would be on blocks with someone straddling the front wheel. Not on a jack.
Tourer
Joined: Dec 2016
Posts: 291
Likes: 128
From: N/A
No updates to give. Picked up a 3/4 breaker bar, but Ive gone all over town looking for a 3/4 drive 6pt 1-1/2 socket and found zilch. Ill have to order it, but Im heading out of town for a month and a half this Sunday, so itll have to wait. Thanks for all the advice.
The nut on my compensating sprocket was an absolute bitch-and-a-half to get off. I ended up using a propane torch to heat the nut, and then used a six foot piece of pipe to give me leverage on the breaker bar (I had a Jims locking bar wedged in between the two sprockets).
Good luck.
Cruiser
Joined: May 2020
Posts: 182
Likes: 68
From: PEI
Where I'm at, in 2015 it snowed solid from feb 14-march 15th, 16 feet was the official total and drifts were much higher. Everything was closed for almost a month and the news was telling kids not to touch the power lines as you could walk right to the tops of the poles.
Seasoned HDF Member
Joined: Mar 2009
Posts: 24,735
Likes: 9,245
From: Snow Hill, NC
Where I'm at, in 2015 it snowed solid from feb 14-march 15th, 16 feet was the official total and drifts were much higher. Everything was closed for almost a month and the news was telling kids not to touch the power lines as you could walk right to the tops of the poles.
HD Forum Stories
The Best of Harley-Davidson for Lifelong Riders
6 Weirdest Harley-Davidsons Ever Sold to the Public
Verdad Gallardo
7 Times Harley-Davidson Chucked Tradition Out the Window
Verdad Gallardo
7 Surprising Harley-Davidson Products that Are Not Motorcycles
Verdad Gallardo
8 Best Harley-Davidson Motorcycles Ever
Pouria Savadkouei
10 Worst Harley-Davidson Motorcycles Ever
Pouria Savadkouei
Killer Custom's Jail Break Is The Breakout That Refused to Blend In
Verdad Gallardo
Crazy Bunderbike Build Looks Amazing, But Is It Impossible to Ride?
Verdad Gallardo
Harley-Davidson Reveals Super Cool Cafe Racer Concept
Verdad Gallardo
Engraved Rebellion: Inside Bundnerbike's Glam Rock II
Verdad Gallardo
Road Captain
Joined: Sep 2018
Posts: 547
Likes: 383
From: Phoenix
Stellar HDF Member
Joined: Mar 2016
Posts: 2,285
Likes: 965
From: Eastern NC
A cold nut in that snow would result in significant shrinkage, no way to the a nut off there.
This thread is spinning out of control!!
Now we have to wait a month and 1/2.....
This thread is spinning out of control!!
Now we have to wait a month and 1/2.....
