Adding a second horn, question for you

Thread Tools

Search this Thread

Old Aug 25, 2009 | 08:08 AM
  #1
128auto's Avatar
128auto
Thread Starter
|
Extreme HDF Member
Joined: Sep 2006
Posts: 10,114
Likes: 29
From: Vancouver B.C. Canada
Default Adding a second horn, question for you

Does anyone add a second horn without an extra relay? I am thinking to add a low tone to give it a boost, can the circuit handle the amperage on 2 horns? Thanks!

Reply
Old Aug 25, 2009 | 08:59 AM
  #2
KumaRide's Avatar
KumaRide
Grand HDF Member
Joined: May 2008
Posts: 4,624
Likes: 188
From: Newcastle, Ca.
Default

Was looking into doing the same thing. A relay "should" be added with its own fuse as those Fiamm horns draw 5 amps each. Look at the stock horn wires, they are not the proper gauge for 10 amps of current nor is the horn switch. You may eventually burn out the horn switch. Also, the horns will not be as loud because they will not get the full 10 amps they require.

Reply
Old Aug 25, 2009 | 09:01 AM
  #3
VTwin-Goodies's Avatar
VTwin-Goodies
Former Sponsor
Joined: Nov 2007
Posts: 47,839
Likes: 1,955
From: SoCal
Default

Just get yourself a WOLO air horn. Yoiu will need a relay with it, but they are really LOUD!

Reply
Old Aug 25, 2009 | 09:06 AM
  #4
KumaRide's Avatar
KumaRide
Grand HDF Member
Joined: May 2008
Posts: 4,624
Likes: 188
From: Newcastle, Ca.
Default

Originally Posted by HarleyGoodies
Just get yourself a WOLO air horn. Yoiu will need a relay with it, but they are really LOUD!
Do you have one? Where did you install it, did you hide it some where?

Reply
Old Aug 25, 2009 | 09:37 AM
  #5
128auto's Avatar
128auto
Thread Starter
|
Extreme HDF Member
Joined: Sep 2006
Posts: 10,114
Likes: 29
From: Vancouver B.C. Canada
Default

I like the sound of an air horn but it doesn't look good on my bike, I would consider if I own a deluxe. I will wire a relay then, not hard.

Reply
Old Aug 25, 2009 | 10:37 AM
  #6
VTwin-Goodies's Avatar
VTwin-Goodies
Former Sponsor
Joined: Nov 2007
Posts: 47,839
Likes: 1,955
From: SoCal
Default

Originally Posted by KumaRide
Do you have one? Where did you install it, did you hide it some where?
A friend has one. http://www.amazon.com/gp/product/B00...d_i=B000F5DQWY

You might need some sort of install kit too. I'll find out.

Reply
Old Aug 25, 2009 | 01:52 PM
  #7
JohnnyBoy's Avatar
JohnnyBoy
Road Captain
Joined: Apr 2007
Posts: 654
Likes: 0
From: Hollywood, California
Default

Yes, anything more than what your have stock will need a seperate dedicated circuit. Not that difficult of a procedure.

Reply
Old Aug 26, 2009 | 07:13 AM
  #8
tk353's Avatar
tk353
Ultimate HDF Member
Joined: Oct 2007
Posts: 5,257
Likes: 6
From: Leander Texas
Default

i was told you can replace the 90db stock horn with one from napa that fits the harley housing and is 134db and under $40.
Item#: BK 7301046
Price: $23.99
Attributes:
Style Name:High Frequency Vibrator Horns
Material:Steel
dB Level:134 db
Horn Note Type:High Note
Heavy Duty Copper Coil Wire Motors
Dual Terminals
All Steel Construction
Pre-Tested For
Power Source:12 VDC (4 Amp Current Draw)
Dimensions:4 1/2" Dia
2 5/8" Depth
Outer Finish:Plated Steel

Manufacturer:FIAMM Technologies
Inc.
Mfg Part Number:BK730-1046


Last edited by tk353; Aug 26, 2009 at 07:17 AM.
Reply
Old Aug 26, 2009 | 08:20 AM
  #9
128auto's Avatar
128auto
Thread Starter
|
Extreme HDF Member
Joined: Sep 2006
Posts: 10,114
Likes: 29
From: Vancouver B.C. Canada
Default

I already have the Fiamm freeway blaster under my cowbell, it is much louder than stock but I want to get more, an additional low tone will do.

Reply
Old Aug 26, 2009 | 08:34 AM
  #10
Chazmanian's Avatar
Chazmanian
R.I.P. BROTHER
Joined: Dec 2008
Posts: 3,076
Likes: 6
From: Colorado Springs
Default

Originally Posted by KumaRide
Was looking into doing the same thing. A relay "should" be added with its own fuse as those Fiamm horns draw 5 amps each. Look at the stock horn wires, they are not the proper gauge for 10 amps of current nor is the horn switch. You may eventually burn out the horn switch. Also, the horns will not be as loud because they will not get the full 10 amps they require.
K-Ride is spot on here. Without a relay and a seperate fused sorce of power directly off the battery you cant do 10Amps.

I ran a fused relay line directly off my battery to power my airhorns. Without that relay and when I tested them just by plugging them directly into the OEM horn wires?

They sounded like a "Pixie" bike from K-Mart.

Ran the relay and power directly off the battery?

Sounded like they came directly off BNSF's finest!!

Reply
