EVO All Evo Model Discussion

cam curious

Thread Tools

Search this Thread

Old Jan 25, 2015 | 08:27 AM
  #41
Dun Roamin's Avatar
Dun Roamin
Banned
Joined: Apr 2014
Posts: 678
Likes: 1
From: LA
Default

Originally Posted by Dr.Hess
To use the original non-adjustable pushrods, you don't have to pull the heads. Just the rocker boxes.
Sorry, I stand corrected. I've never done it that way. Presumably it involves removing the rocker arms? Is there a knack to it?

Yes, glidein, it's often the most expedient way, particularly if you're fitting a more radical cam or have skimmed the heads and want to use adjustable pushrods. You'll save time and hassle so it's also a pay off if you're putting your bike into a shop to do it ... lift the top end costs.

It depends what you want to achieve. If you don't want to inspect and redo or develop the head, then it's probably the way to go.

Reply
Old Jan 25, 2015 | 09:07 AM
  #42
Dr.Hess's Avatar
Dr.Hess
Seasoned HDF Member
15 Year Member
Liked
Loved
Community Favorite
Joined: Aug 2007
Posts: 8,194
Likes: 3,082
From: NW AR
Default

I've done it both ways. Cutting the old ones saves a lot of time.

Reply
Old Jan 25, 2015 | 09:29 AM
  #43
glidein wide's Avatar
glidein wide
Thread Starter
|
Stellar HDF Member
10 Year Member
Photogenic
Liked
Joined: Jan 2015
Posts: 2,504
Likes: 150
From: ct
Default

Well I just did a compression test and had 130# in front &145# in rear, I would say that makes me happy.

Reply
Old Jan 25, 2015 | 09:32 AM
  #44
tmanbuckhunter's Avatar
tmanbuckhunter
Outstanding HDF Member
Joined: Jul 2013
Posts: 2,874
Likes: 36
From: Houston, TX
Default

Originally Posted by glidein wide
Well I just did a compression test and had 130# in front &145# in rear, I would say that makes me happy.
Generally a 10psi difference between the two is acceptable... you have a 15psi difference there. Might be getting into a bigger job than you planned on.

Reply
Old Jan 25, 2015 | 10:01 AM
  #45
Schex's Avatar
Schex
Club Member
15 Year Member
Joined: Apr 2011
Posts: 5,765
Likes: 7,801
From: SE Louisiana
Riders Club Member
Default

Originally Posted by glidein wide
Well I just did a compression test and had 130# in front &145# in rear, I would say that makes me happy.
That would make me tear into it, 10% difference.

Not acceptable for me, but that's me, good for some as long as it runs.

Reply
Old Jan 25, 2015 | 11:02 AM
  #46
Dun Roamin's Avatar
Dun Roamin
Banned
Joined: Apr 2014
Posts: 678
Likes: 1
From: LA
Default

Exhaust valve worn, guide seals are probably hard too ... will still go for 10,000s so it depends what he wants to do with this time this winter!

Reply
Old Jan 25, 2015 | 11:20 AM
  #47
98hotrodfatboy's Avatar
98hotrodfatboy
Seasoned HDF Member
15 Year Member
Liked
Loved
Top Answer: 5
Joined: Mar 2010
Posts: 20,964
Likes: 7,496
From: Poolville
Default border line...

You are border line to doing a valve job that is what I would think based on todays fuels and your mileage. The rings are probably still good but with the addition of a new cam I would do the heads. Redo a compression test with oil and then a leak down to confirm..

Reply
Old Jan 25, 2015 | 11:25 AM
  #48
D_gyver's Avatar
D_gyver
Road Master
Joined: Feb 2014
Posts: 913
Likes: 5
From: indiana
Default

Originally Posted by glidein wide
Well I just did a compression test and had 130# in front &145# in rear, I would say that makes me happy.

stock compression on your bike should be around 150psi +/- 10 the 130 is to low. and the difference between cylinders should never be more than 10psi.


now you need to locate the problem by doing a leakdown test to find out where your loosing you compression if you don't have a leakdown tester
you can put one ounce of oil in the cylinder and do the compression test again if the compression comes back its your rings if it doesn't its your valves

Reply
Old Jan 25, 2015 | 11:57 AM
  #49
glidein wide's Avatar
glidein wide
Thread Starter
|
Stellar HDF Member
10 Year Member
Photogenic
Liked
Joined: Jan 2015
Posts: 2,504
Likes: 150
From: ct
Default

Originally Posted by D_gyver
stock compression on your bike should be around 150psi +/- 10 the 130 is to low. and the difference between cylinders should never be more than 10psi.


now you need to locate the problem by doing a leakdown test to find out where your loosing you compression if you don't have a leakdown tester
you can put one ounce of oil in the cylinder and do the compression test again if the compression comes back its your rings if it doesn't its your valves
I will be trying that next, though my service manual states that 90#+is sufficient, less than that there is a problem. Don't believe everything I read right?

Reply
Old Jan 25, 2015 | 12:17 PM
  #50
Tee&Vee's Avatar
Tee&Vee
Stellar HDF Member
10 Year Member
Liked
Loved
Community Favorite
Joined: Jul 2011
Posts: 2,583
Likes: 115
From: Boston, MA
Default

Reread Schex3x's post #45. It's not the amount, per se, it's the difference of the amounts. I have no stake in this but perhaps you could PM Scott@hillside and get his estimates for a nice overhaul. No need, can the wants, to buy a Wood w8H and all other 11:1 pistons and the accompanying financial mess. Hillside is a proven site sponsor. Heck, pm John Z and ask for his recommendations and pricing.
It's only your money that we want to spend...
Tom
