Installed 21" wheel. Now ABS problem?
Cruiser
Joined: Jun 2012
Posts: 119
Likes: 99
From: Brazil
Yes, we checked the area with a steel bar, but I don't remember what was the diameter. We put it between the tire and the fender and still ran free.
Cruiser
Joined: Jun 2012
Posts: 119
Likes: 99
From: Brazil
Sorry to hear this. I spent countless posts warning people of the possibility of tire/fender contact when we do a 21 swap. And far more often than not I get responses like..... I just bolted mine on and never had an issue, so I'm gonna stick my head in the sand and pretend this issue doesn't exist. In my case I made some brackets and lifted the fender about 3/4 of an inch. Or you can buy the 1 inch fender lifts, but they make it so lowering the bike can also be an issue. Either way, I hope you get this worked out.
Do you have pics of your fender lift? My plan would raise it 1/2 inch. But now I'm considering 3/4 inch.
Ultimate HDF Member
Joined: Jun 2007
Posts: 9,193
Likes: 494
From: Richmond, VA
[QUextensionsodeserto;14983832]There is little information in Brazil about this change. The dealers do not sell or install. I asked for a budget with three importers, but none of them warned me about the need of the lifter for a bike like mine.
Do you have pics of your fender lift? My plan would raise it 1/2 inch. But now I'm considering 3/4 inch.[/QUOTE]
In most cases brackets like i made are over kill. They are required on the 14 and up. Usually on the 13 and older you can just drill out the rear mounting holes with a 3/8 drill bit, raise up the rear of the fender and your good to go. Other wise ebay has them for sale.
Im on my cell phone so no pics, but i just welded extensions on and repainted the brackets. I would use the one inch chrome brackets if I ever did it again. Or of course try drilling out the rear mounting holes.
Edit, I found a pic. Probablly not much help, but you can see the fender is closer to the trees. If you really zoom in you can kinda see the mounts are longer than stock.
Do you have pics of your fender lift? My plan would raise it 1/2 inch. But now I'm considering 3/4 inch.[/QUOTE]
In most cases brackets like i made are over kill. They are required on the 14 and up. Usually on the 13 and older you can just drill out the rear mounting holes with a 3/8 drill bit, raise up the rear of the fender and your good to go. Other wise ebay has them for sale.
Im on my cell phone so no pics, but i just welded extensions on and repainted the brackets. I would use the one inch chrome brackets if I ever did it again. Or of course try drilling out the rear mounting holes.
Edit, I found a pic. Probablly not much help, but you can see the fender is closer to the trees. If you really zoom in you can kinda see the mounts are longer than stock.
Last edited by bikerlaw; Mar 28, 2016 at 09:08 AM.
6th Gear
Joined: Sep 2012
Posts: 14
Likes: 1
From: las vegas, nv
If the problem originates from the tone ring (bearing), it won't set a code because it's not electrical. The module thinks all electrical is good and the bike is just trying to lock up. I would make sure the bearing is definitely for ABS and that it is good. Have you tried to see if there is a constant and consistent signal coming from the sensor while spinning the wheel?
Club Member
Joined: Oct 2011
Posts: 11,175
Likes: 2,484
From: Nor Cal
If the problem originates from the tone ring (bearing), it won't set a code because it's not electrical. The module thinks all electrical is good and the bike is just trying to lock up. I would make sure the bearing is definitely for ABS and that it is good. Have you tried to see if there is a constant and consistent signal coming from the sensor while spinning the wheel?
BACK TO WORK!
Signed, "BossOfCityWorker"
Thread Starter
|
Advanced
Joined: Jun 2014
Posts: 97
Likes: 5
From: North Carolina
If the problem originates from the tone ring (bearing), it won't set a code because it's not electrical. The module thinks all electrical is good and the bike is just trying to lock up. I would make sure the bearing is definitely for ABS and that it is good. Have you tried to see if there is a constant and consistent signal coming from the sensor while spinning the wheel?
Cruiser
Joined: Jun 2012
Posts: 119
Likes: 99
From: Brazil
We tested the signal and the sensor position. We could not find anything wrong.
Tomorrow we will replace the bearings.
The fender lifters were finished today. I have to decide if I will paint or chroming it.
Tomorrow we will replace the bearings.
The fender lifters were finished today. I have to decide if I will paint or chroming it.
Former Sponsor
Joined: Jul 2009
Posts: 2,744
Likes: 11
I may have missed it but what is the year of the bike? Any of the bikes equipped with the reflex-linked brakes have issues when going to a 21" front wheel. You do have a couple of options. Thunder Max makes a module called the Trac Max which calibrates so the linked brakes/abs will work correctly. Now MC Baggers has a bearing that does the same thing but much less expensive. They make a bearing for the 21", 23", 26" and 30".
The fender rub sucks! Someone gave good info as drilling out the rear two mounting holes with a 3/8" drill bit. We do this on every install we do (2013-older) and I send an instruction sheet with every wheel is send out (2013-older).
The fender rub sucks! Someone gave good info as drilling out the rear two mounting holes with a 3/8" drill bit. We do this on every install we do (2013-older) and I send an instruction sheet with every wheel is send out (2013-older).
HD Forum Stories
The Best of Harley-Davidson for Lifelong Riders
6 Weirdest Harley-Davidsons Ever Sold to the Public
Verdad Gallardo
7 Times Harley-Davidson Chucked Tradition Out the Window
Verdad Gallardo
7 Surprising Harley-Davidson Products that Are Not Motorcycles
Verdad Gallardo
8 Best Harley-Davidson Motorcycles Ever
Pouria Savadkouei
10 Worst Harley-Davidson Motorcycles Ever
Pouria Savadkouei
Killer Custom's Jail Break Is The Breakout That Refused to Blend In
Verdad Gallardo
Crazy Bunderbike Build Looks Amazing, But Is It Impossible to Ride?
Verdad Gallardo
Harley-Davidson Reveals Super Cool Cafe Racer Concept
Verdad Gallardo
Engraved Rebellion: Inside Bundnerbike's Glam Rock II
Verdad Gallardo
Cruiser
Joined: Jun 2012
Posts: 119
Likes: 99
From: Brazil
I may have missed it but what is the year of the bike? Any of the bikes equipped with the reflex-linked brakes have issues when going to a 21" front wheel. You do have a couple of options. Thunder Max makes a module called the Trac Max which calibrates so the linked brakes/abs will work correctly. Now MC Baggers has a bearing that does the same thing but much less expensive. They make a bearing for the 21", 23", 26" and 30".
The fender rub sucks! Someone gave good info as drilling out the rear two mounting holes with a 3/8" drill bit. We do this on every install we do (2013-older) and I send an instruction sheet with every wheel is send out (2013-older).
The fender rub sucks! Someone gave good info as drilling out the rear two mounting holes with a 3/8" drill bit. We do this on every install we do (2013-older) and I send an instruction sheet with every wheel is send out (2013-older).
My bike is 2011.
http://mcbaggers.com/product/ar14-21/
Does this bearing is compatible with DNA wheel?
Last edited by aguiadodeserto; Apr 5, 2016 at 12:21 PM.
Former Sponsor
Joined: Jul 2009
Posts: 2,744
Likes: 11
Thanks!
My bike is 2011.
http://mcbaggers.com/product/ar14-21/
Does this bearing is compatible with DNA wheel?
My bike is 2011.
http://mcbaggers.com/product/ar14-21/
Does this bearing is compatible with DNA wheel?
This type of bearing is specifically for the linked brake bikes which started in 2014.
