"DYNO" Numbers For SOFTAILS
Road Master
Joined: Jul 2007
Posts: 1,016
Likes: 1
From: Front Royal, VA
Open it and size it on your screen. Then take a screenshot (alt+print screen). Then paste it into a program like Paint and save it as a jpg file. It should be small enough. Hope that works for ya.
Outstanding HDF Member
Joined: Oct 2007
Posts: 2,018
Likes: 6
From: Edmond, Ok
Ok, after many failed attempts, I'm just took pics of the sheet....I realize that you probably can't see the run conditions, but here they are:
1/14/09 Run Conditions: 74.77*F, 29.26 in-HG, Humidity: 6%, SAE: 1.00
Max Power: 98.00 Max Torque: 109.20
'07 FXST, Baisley Super Stock Heads (1.94 intake, 1.63 exhaust; 82.3 cc chambers)
Wood TW6G7 cams, D&D Fat Cat w/ standard baffle, tuned with PCIII
1/14/09 Run Conditions: 74.77*F, 29.26 in-HG, Humidity: 6%, SAE: 1.00
Max Power: 98.00 Max Torque: 109.20
'07 FXST, Baisley Super Stock Heads (1.94 intake, 1.63 exhaust; 82.3 cc chambers)
Wood TW6G7 cams, D&D Fat Cat w/ standard baffle, tuned with PCIII
Thread Starter
|
Club Member
Joined: May 2007
Posts: 145,895
Likes: 821
From: 40 miles Northeast of Indy..
If U look at the smoothing # its zero, thats way it was jumping all over..usually its 5.
Cruiser
Joined: Mar 2009
Posts: 127
Likes: 0
From: Las Vegas
103 ci
SE 110 + heads - ported
SE 10.5 high compression pistons
SE 58 mm throttle body
SE 260 cam
SE intake - ported
Bassani stepped Road Rage 2 into 1 (short)
SE Push Rods
4.9 injectors
SE Heavy Breather
.030 cometic head gaskets
SE Super Race Tuner
Dyno tuned by Gil Nevarez @ NRP (Las Vegas)
119 RWHP / 113 FT LB... in 100+ degree weather with a corrected altitude of 6000 feet...
SE 110 + heads - ported
SE 10.5 high compression pistons
SE 58 mm throttle body
SE 260 cam
SE intake - ported
Bassani stepped Road Rage 2 into 1 (short)
SE Push Rods
4.9 injectors
SE Heavy Breather
.030 cometic head gaskets
SE Super Race Tuner
Dyno tuned by Gil Nevarez @ NRP (Las Vegas)
119 RWHP / 113 FT LB... in 100+ degree weather with a corrected altitude of 6000 feet...
Last edited by Troy L; Jul 30, 2009 at 07:23 PM.
Novice
Joined: Mar 2008
Posts: 19
Likes: 0
From: Vancouver Wa
Just a basic stage #1 on factory 88 CI
Numbers after my first tune on the PCIII USB
Stats in signature
Numbers after my first tune on the PCIII USB
Stats in signature
